Warranty:
10 Years
Packaging Description:
Plastic shrink wrap with cardboard end protection
Type:
Double Panel / Single Convector
Material:
Mild Steel
Product Finish:
Painted
Colour:
Traffic White (RAL 9016)
Paint Finish:
Semigloss
Custom RAL Colour Available:
Yes
Custom Micrograin Texture Available:
No
Custom Crocodile Texture Available:
No
Custom Wood Effect Available:
No
Custom PVD Finish Available:
No
Custom Anodised Finish Available:
No
Certifications:
CE, ISO 9001, UKCA
Standards:
BS EN 442-1:2014
Height (mm):
1800
Length (mm):
400
Depth (mm):
77
Net Product Weight (kg):
38.4
Orientation/Mounting Position:
Vertical
Pipes/Sections:
12
Towel Gaps:
N/A
Wall to Face (mm):
103 or 125
Pipe Centres (mm):
E1: 344
Wall to Pipe Centres (mm):
65 or 87
Bracket Centres - Horizontal (mm):
222
Bracket Centres - Vertical (mm):
1685
Fuel Type Available:
Hot Water
Maximum Working Pressure (Bar):
10
Maximum Working Temperature (ºC):
95
System:
Closed
Heat Output (BTU):
4176
Heat Output Group (BTU):
4001 – 4500 BTU
Heat Output (W):
1224
Heat Output Group (W):
1001 – 1500 Watts
Water Content (L):
6.6
