Warranty:
10 Years
Packaging Description:
Plastic shrink wrap with cardboard end protection
Type:
Single Panel / Single Convector
Material:
Mild Steel
Product Finish:
Painted
Colour:
Traffic White (RAL 9016)
Paint Finish:
Semigloss
Custom RAL Colour Available:
Yes
Custom Micrograin Texture Available:
No
Custom Crocodile Texture Available:
No
Custom Wood Effect Available:
No
Custom PVD Finish Available:
No
Custom Anodised Finish Available:
No
Certifications:
CE, ISO 9001, UKCA
Standards:
BS EN 442-1:2014
Height (mm):
2000
Length (mm):
400
Depth (mm):
57
Net Product Weight (kg):
30.24
Orientation/Mounting Position:
Vertical
Pipes/Sections:
12
Towel Gaps:
N/A
Wall to Face (mm):
80 or 79
Pipe Centres (mm):
E1: 344
Wall to Pipe Centres (mm):
39 or 61
Bracket Centres - Horizontal (mm):
254
Bracket Centres - Vertical (mm):
1085
Fuel Type Available:
Hot Water
Maximum Working Pressure (Bar):
10
Maximum Working Temperature (ºC):
95
System:
Closed
Heat Output (BTU):
3136
Heat Output Group (BTU):
3001 – 3500 BTU
Heat Output (W):
919
Heat Output Group (W):
501 – 1000 Watts
Water Content (L):
3.72
