For prices call us on 01908 272444 or contact your sales representative.



4 Column 500 Horizontal Radiator: Traffic White (RAL 9016) 500mm H x 598mm L - 4-Column-C4050613W-White-Lifestyle-01.jpg

4 Column 500 Horizontal Radiator: Traffic White (RAL 9016) 500mm H x 598mm L

SKU:
C4050613-W

Product Description


Understated power: This timeless classic really means it when it comes to providing excellent heat output, along with unmistakable, iconic style. The 4 Column 400 is a 400mm high, mild steel, columnar radiator that brings traditional style up-to-date. (Feet/floor brackets available separately.)
  • Material / Finish : Mild Steel / Painted in Semigloss Traffic White (RAL 9016)
  • Dimensions : 500mm H x 598mm L x 140mm D
  • Heat Output at ΔT 50º C : 3196 BTU
  • Max Working Temperature : 95º C / Working Pressure: 6 Bar
  • Warranty : 5 Years

    • Other Details

    Warranty:
    5 Years
    Packaging Description:
    Plastic wrap with cardboard end protection and inner bubble wrap
    Type:
    Quad
    Material:
    Mild Steel
    Product Finish:
    Painted
    Colour:
    Traffic White (RAL 9016)
    Paint Finish:
    Semigloss
    Custom RAL Colour Available:
    Yes
    Custom Micrograin Texture Available:
    Yes
    Custom Crocodile Texture Available:
    No
    Custom Wood Effect Available:
    No
    Custom PVD Finish Available:
    No
    Custom Anodised Finish Available:
    No
    Certifications:
    CE, ISO 9001, UKCA
    Standards:
    BS EN 442-1:2014
    Height (mm):
    500
    Length (mm):
    598
    Depth (mm):
    140
    Net Product Weight (kg):
    24.3
    Orientation/Mounting Position:
    Horizontal
    Pipes/Sections:
    13
    Towel Gaps:
    N/A
    Wall to Face (mm):
    170
    Pipe Centres (mm):
    E2: 685 / E3: 420
    Wall to Pipe Centres (mm):
    100
    Bracket Centres - Horizontal (mm):
    (4 brackets) F0 = 443
    Bracket Centres - Vertical (mm):
    420
    Fuel Type Available:
    Hot Water
    Maximum Working Pressure (Bar):
    6
    Maximum Working Temperature (ºC):
    95
    System:
    Closed
    Heat Output (BTU):
    3196
    Heat Output Group (BTU):
    3001 – 3500 BTU
    Heat Output (W):
    936
    Heat Output Group (W):
    501 – 1000 Watts
    Water Content (L):
    13.975
